REOTEMP
Reotemp D20 0-10 PSID 1/4" NPTF Back Process Connection 2.5" Dial Differential Pressure Gauge w/ Max Pointer
Reotemp D20 0-10 PSID 1/4" NPTF Back Process Connection 2.5" Dial Differential Pressure Gauge w/ Max Pointer
SKU:ITM24070727
REOTEMP 0-10 PSID Differential Pressure Gauge w/ Max Pointer, Piston Type, 2.5" Dial Size, NPTF Back Process Connection, Stainless Steel & Buna Wetted Materials
Regular price
$717.00 USD
Regular price
Sale price
$717.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Share
Product Details
Features
- Reotemp's Series D20 Piston Type Mechanical Differential Pressure Gauges are primarily designed for liquid applications
- Differential pressure is sensed by the movement of a precisely ground floating piston/magnet in a precision bore against a calibrated spring
- A rotary pointer magnet located close to the internal magnet follows the movement of the piston magnet and indicates differential pressure on the dial
- Piston type differential pressure gauges exhibit a slight amount of bypass as the fluid crosses from the high to the low pressure port
- Over-range Protection to Max Working Pressure
Specifications
- Product Series: D20
- Wetted Material: Stainless Steel & Buna
- Case Material: Plastic
- Pressure Range: 0 to 10 PSID with Max Pointer
- Dial Size: 2.5"
- Connection Size & Location: 1/4" FNPT Back Connection
- Accuracy: +/- 2% - 5% Ascending
