NOSHOK

Flare Pattern Flange-Female SS Noshok 5-Valve Manifold Valve

Flare Pattern Flange-Female SS Noshok 5-Valve Manifold Valve

ITM22057584

Noshok 2-1/2" Analog Pressure Gauge 304 Stainless Steel Case, Copper Alloy Internals, 3,000 psi/kPa, 1/4" National Pipe Thread (NPT) Male Back Connection Analog Pressure Gauge with Glycerin Filled

$814.57 USD
$814.57 USD
Sale Sold out
Shipping calculated at checkout.
View full details

Product Details

Features

  • Designed for use with differential pressure transmitters incorporating two isolation valves, two equalizing valves and a vent valve required in natural gas applications
  • Flare Pattern™ valve configuration provides maximum clearance for fingers during operation
  • Soft tip valves feature a patented Acetal non-rotating soft tip stem, and a back-up metal-to-metal seal (U.S. Patent 6,820,857)

Specifications

  • Product Series: 5530 Series 0.375" Orifice Natural Gas 5 Manifold Valve
  • Process & Valve Type: Natural Gas Flow, Flange-Female
  • Connection Size: 1/2" NPT
  • Materials: Electropolished 316 Stainless Steel
  • Stem Seal and Type: All 316 Stainless Steel stems with Fluorocarbon (FKM) o-ring and Polytetrafluoroethylene (PTFE) back-up ring below the threads
  • Pressure Ratings at 200 Degree Fahrenheit Temperature: 6,000 psi
  • Orifice Size: 0.375"
